The Next Generation Landoll Trailer Has Arrived!
The Landoll trailer line is taking a huge leap forward with the introduction of the all-new Hydraulic Operating Systems (HOSS) and High-Visibility Lighting package. The 440 and 455 B-Series Traveling Axle Trailers are the first models with these newly added standard features.
HOSS cuts the overall operational time in half. The axle forward travel is 36% faster, and 58% faster moving back. Tilt-deck positioning is nearly 63% faster, and winch in/out speeds have increased 66%.
Stability with Top Performance and Maneuverability
The 455B Traveling Axle Trailer can handle heavy loads with it’s triple axles and 55-ton capacity. Available in lengths of 48’, 50’, 53’, 57′ and California legal 50’. To maximize the load capacity, the 455B includes 60” axle spread standard.
Increased frame capacity is one of the outstanding features of the 455B along with wider main beams, wider undercarriage, wider tilt cylinder mounts and wider outer beam pivot points.
Low Clearance Upper Deck Transition
All 400 series trailers feature the super low clearance slope transition allowing man lifts, forklifts, and other difficult low clearance equipment to easily load the upper deck.
Ultimate Stability
The four beam frame design is the backbone of a super versatile, solid piece of equipment. Wider main beams with a wider undercarriage, outboard tilt cylinder mounts, and outer beam pivot points add superior stability while loading heavy loads.
Powder Coat Paint
Landoll is the only trailer manufacturer to offer powder coat paint on an entire trailer frame. The very durable finish provides excellent chemical and salt resistance while giving Landoll trailers a high quality, attractive appearance. A zinc-rich powder primer is applied prior to painting the entire frame with one of eight standard powder coat colors.
Railroad Track Option
The railroad track option is ideal for safely loading and transporting today’s rail maintenance equipment. The Landoll approach plate sits down onto the rail to create a solid base and smooth transition from rail to trailer without ramps or heavy drop-in-rails, allowing operators to load these machines within minutes.
Features
Frame & General
| Capacity* | 55 Ton (110,000 lbs.) |
|---|---|
| Deck Rating | 70,000 lbs. in 10′ |
| Estimated Base Weight | To be updated |
| Main Frame | Fabricated 80,000 and 100,000 PSI Yield, 40″ Beam Centers |
| Crossmembers | 4″ Junior I-Beam on 8″ Centers |
| Pin Setting | 21″ |
| Swing Clearance | 80″ |
| Hitch | 5th-Wheel 2″ Kingpin |
| Deck Width | 102″ |
| Slope Drop | 90° |
| Loaded Deck Height | 37″ |
| Loaded Ground Clearance | 14″ at Bottom of Gooseneck |
| Decking | 1-3/8″ Apitong Hardwood |
| Load Angle | 6.5° |
| Accessories | Flat Approach Plate with 6 Key Hole Tie Downs, Main Deck Center Slope Roller, Forklift Package Standard, 410-48CA & 410-50 have 40′ Kingpin to Rear Axle with 9′ 11″ Axle Spread |
| Tie Downs | Double Key Hole Chain Slots with Square Stake Pockets on 16″ Centers |
| Tool Box | Twin Upper Deck Mounted Top-Opening with Non-Weight Bearing Lid Illuminated |
| Parking Stands | Jost Two Speed Landing Gear |
* Capacity ratings are frame capacities only. Actual load capacities may be restricted by factors such as gross axle weight ratings (GAWR) or state and federal regulations.
Suspension & Undercarriage
| Suspension | Neway Air Ride RLU228, 22,500 lbs. Capacity |
|---|---|
| Undercarriage | 4″ x 100″ and 4″ x 126″; Accepts After-Market Dock Level Hydraulics System; Powder Coated Black |
| Grease | Centralized Grease System |
| Axles | (3) 25,000 lbs. Axles, Dual Tire, Oil Bath Bearings, Automatic Slack Adjusters Axles Prepped for Air Inflation |
| Brakes | 12.25 x 7.5 Full Air / Spring Brakes ABS, 4S2M / Center Axle Indirect |
| Tires | 235/75R 17.5 LRJ Double Coin Tires |
| Rims | 17.5 x 6.75 Tubeless Rims |
| Wheels | Steel Hub Pilot |
| Oil Seal Hubs | Internal Mated Assembly |
Hydraulics
| Hydraulic Hook Up | Quick Couplers 2,500 PSI – 20 GPM at Controls, 50 GPM Max |
|---|---|
| Tilt Cylinders | (2) 6″ x 30″ |
| Hydraulic Winch | 12,000 lb. Worm Gear with Spring Tension and 85′ of 1/2″ Cable |
| Hydraulic Valve Body | Rexroth |
Electrical
| Air / Electrical | 7-Way Receptacle |
|---|---|
| Lights | Grote MicroNova® LED Clear Lens-Enhanced Stop, Tail & Turn; Rear Amber Strobe (10-Year Warranty) |
| Wiring Harness | Grote “Xtreme” Wiring Harness (7-Year Warranty) |
Finish & Color
| Finish | Steel Grit Shot Blast to Bright Metal, Zinc Rich Primer |
|---|---|
| Powder Coat Color | White, Black, Yellow, Blue, Red, Green, Metallic Gray, Sapphire Blue |
| Decals | Hi-Visibility Reflective Package |
Options
Base
| Deck Width | 8′ 6″ Wide Deck (Standard) 9′ Wide Deck (Canadian RTAC Compliant) 10′ Wide Deck (Canadian RTAC Compliant) |
|---|---|
| Deck Extensions | 27″ Aluminum Pull-Outs (Capacity Not to Exceed 50% of Trailer Capacity) Swing-Out Outrigger (Capacity Not to Exceed 50% of Trailer Capacity) |
| Hydraulic Kicker Rollers (8 Rollers) | |
| Arctic Hose Package (Upgrades Air and Hydraulic Lines) | |
| Heavy Duty Gooseneck (Adds 2′ to Trailer Length and 23.5″ to Swing Clearance) | |
| Railroad Track for Upper and Lower Dec | |
Bulkhead
| Bulkhead | 16″/24″ x 102″ 2 Position Bulkhead/Front Extension (Solid, 3,000 lbs. distributed capacity) (Powder Coat Black) 48″ x 102″ Mesh Steel Bulkhead (Powder Coat Black) |
|---|---|
| NOTE: All Bulkhead options require the 48″ x 102″ Bulkhead | |
| Bulkhead Wings | Steel Wings (Powder Coat Black) Aluminum Wings |
| Aluminum LED Light Bar (Stop, Turn, and Tail Lights) with Chain Binder Rack | |
| Dual LED Work Lights mounted on Light Bar | |
| Dual Class II Strobe Beacons mounted on Light Bar | |
| Bolt-On Chain-Binder Rack | |
| Dual LED Work Lights mounted on Bulkhead | |
| Dual Class II Strobe Beacons mounted on Bulkhead | |
| Spare Tire Carrier | Rear Mounted Front Mounted Dual Front Mounted |
| Propane Carrier mounted on Bulkhead | Rear Street Side Mounted Rear Curb Side Mounted Both Rear Street and Curb Side Mounted Front Street Side Mounted Front Curb Side Mounted Both Front Street and Curb Side Mounted |
Parking Stands
| Parking Stands | Pin Drop Jost 2 Speed (Standard) Hydraulic |
|---|
Winch & Accessories
| Winch | Delete Standard 12K Braden, Worm Gear 12K Braden, Worm Gear (Standard) 20K Braden, Worm Gear 20K Braden, Worm Gear with Pivoting Cable Roller Guide and Air Release/Air Tension 20K Warn, Planetary, 2 Speed with Air Release/Spring Tension 30K Warn, Planetary, 2 Speed with Air Release/Spring Tension |
|---|---|
| Winch Guard | |
| Dual LED Worklights mounted on the Winch Guard | |
| Cable Roller Guide (4-Way Rollers) | |
| Bolt-On D-Rings at Rear of Winch | Street Side Curb Side |
| Bolt-On D-Rings at Rear of Winch | Both Street and Curb Side |
| Upper Deck Slope Wear Protection | Wear Plate (Standard) Slope Roller |
| Wireless Remote Control (6 function: tilt, travel, and winch) | |
Suspension & Undercarriage
| Hydraulic Dock Leveler, 2 Legs (62K capacity) | |
|---|---|
| Hydraulic Dock Leveler, 4 Legs (124K capacity) | |
| Air Dump Valve | |
| Scale System | Liquid Filled Air Pressure Gauge Air-Weigh LoadMaxx Digital Scale (Trailer only) |
| LoadMaxx ComLink Cable Kit (Cable connects trailer unit to tractor scale) (Requires LoadMaxx Digital Scale) | |
| Shock Straps, Wire Rope | |
| Hardened Undercarriage Cylinders (Recommended with the Arctic Package) | |
| Powder Coat Bumper (Standard) | |
| Hot Dip Galvanized Bumper (In lieu of Standard) (Included with Galvanized Frame) | |
| Strobe Lights in Bumper (2 Amber) (Remove) | |
Hydraulic Power Source
| Hydraulic Quick Coupler Kit (1 male, 1 female) | |
|---|---|
| Kohler EFI, 25 HP, Gas Powered Hydraulic Engine Package with Cover | Upper Deck Mounted Front Extension Mounted |
Tie Downs
| Flush Mounted Straight D-Ring (Not available for web mount) | |
|---|---|
| Angled D-Rings (Mounted under Top Flange Outer Beam) | |
| Low Profile Strap Ratchet | |
| 3-Bar Strap Ratchet | |
| J-Hook (Opposite side of Ratchet) | |
| Stake Pocket (Opposite side of Ratchet) | |
| Chain Rub Rail (Per foot) (Setting price based on 440-53 length) |
Tie Downs – Upper Deck
| Upper Deck Center Keyhole Tie Downs Flush with Wood | |
|---|---|
| Upper Deck Corner Mounted D-Ring Tie Downs on Top Flange | 2 Front Corner 4 Corner |
| Upper Deck Chain/Rub Rails for Both Street and Curb Side | |
| Upper Deck Chain/Rub Rails for Both Street and Curb Side (Heavy Duty Gooseneck) | |
| Upper Deck Web Mounted Tie Downs | Stake Pockets (Inside web, under every gotcha) Angled D-Rings (Mounted under Top Flange, 2 per side) Low Profile Strap Ratchet with J-Hook Opposite (2 alternating) Low Profile Strap Ratchet with J-Hook Opposite (3 alternating) (Heavy Duty Gooseneck only) Low Profile Strap Ratchet with Stake Pocket Opposite (2 alternating) Low Profile Strap Ratchet with Stake Pocket Opposite (3 alternating) (Heavy Duty Gooseneck only) 3-Bar Strap Ratchet with J-Hook Opposite (2 alternating) 3-Bar Strap Ratchet with J-Hook Opposite (3 alternating) (Heavy Duty Gooseneck only) 3-Bar Strap Ratchet with Stake Pocket Opposite (2 alternating) 3-Bar Strap Ratchet with Stake Pocket Opposite (3 alternating) (Heavy Duty Gooseneck only) |
Tie Downs – Lower Deck
| Lower Deck Center Keyhole Tie Downs Flush with Wood | |
|---|---|
| Lower Deck Chain/Rub Rails for Both Street and Curb Side (440A-41) | |
| Lower Deck Chain/Rub Rails for Both Street and Curb Side (440A-48) | |
| Lower Deck Chain/Rub Rails for Both Street and Curb Side (440A-50CA) | |
| Lower Deck Chain/Rub Rails for Both Street and Curb Side (440A-53) | |
| Lower Deck Web Mounted Tie Downs | Stake Pockets (Inside web, under every other gotcha) Angled D-Rings (Mounted under Top Flange, 6 per side) Angled D-Rings (Mounted under Top Flange, 10 per side) Angled D-Rings (Mounted under Top Flange, 16 per side) (53′ models only) Low Profile Strap Ratchet with J-Hook Opposite (6 alternating) Low Profile Strap Ratchet with J-Hook Opposite (11 alternating) Low Profile Strap Ratchet with J-Hook Opposite (16 alternating) (53′ models only) Low Profile Strap Ratchet with Stake Pocket Opposite (6 alternating) Low Profile Strap Ratchet with Stake Pocket Opposite (11 alternating) Low Profile Strap Ratchet with Stake Pocket Opposite (16 alternating) 3-Bar Strap Ratchet with J-Hook Opposite (6 alternating) 3-Bar Strap Ratchet with J-Hook Opposite (11 alternating) 3-Bar Strap Ratchet with J-Hook Opposite (16 alternating) (53′ models only) 3-Bar Strap Ratchet with Stake Pocket Opposite (6 alternating) 3-Bar Strap Ratchet with Stake Pocket Opposite (11 alternating) 3-Bar Strap Ratchet with Stake Pocket Opposite (16 alternating) (53′ models only) |
Paint & Special
| Undercoating (Petroleum Based) | |
|---|---|
| Anti-Slip Paint on Inner and Outer Flanges | Black Yellow |
| Standard Landoll Branded Decals (Affects Lower Deck Only) | |
| Hot Dip Galvanizing | |
| NOTE: Powder Coat Paint only available with Non-Galvanized Trailers | |
| Powder Coat Paint Colors | Black (Standard), Anniversary Gray, White, Red, Viper Red, Blue, Sapphire Blue, Yellow, Green |
| Paint over Galvanizing (Side Frame Web Only) | |
| Paint over Galvanizing (Top Surfaces) | |
| NOTE: Wet Paint only for Galvanized Trailer | |
| Wet Paint Colors | Black (Standard), Anniversary Gray, White, Red, Viper Red, Blue, Sapphire Blue, Yellow, Green |
Upper Deck & Accessories
| Toolboxes | Non-Load Bearing Top Opening Toolboxes (Standard) Load Bearing, Self-Supporting, Top Opening Toolboxes Side Opening Toolboxes Side Opening Toolboxes (Remove) Non-Load Bearing Top Opening Toolboxes (Standard) Load Bearing, Self-Supporting, Top Opening Toolboxes |
|---|---|
| Spare Tire Carrier in Front Stake Pocket | Street Side Curb Side Both Street and Curb Side |
| Front Flip Extension Ramps (In track area) | |
| Slope Filler (Bolt-on, makes Upper Deck level) | |
| Slope Mounted Dual LED Work Lights | |
| Mud Flaps Mounted Under Gooseneck (Slope splash shield) | |
Lower Deck & Accessories
| Folding Step(s) | Street Side (Painted Safety Yellow) Curb Side (Painted Safety Yellow) Both Street and Curb Side (Painted Safety Yellow) |
|---|---|
| Toe Boards (3/8″ x 2-1/2″) | |
| Skid Plates | Container Skid Plates Flush with Outer Flange (3/8″ x 6″ for 8′ 6″ wide trailer) Container Skid Plates Flush with Outer Flange (3/8″ x 10-1/2″ for 9′ wide trailer) Container Skid Plates Flush with Outer Flange (3/8″ x 14-3/4″ for 10′ wide trailer) Container Skid Plates Flush with Wood Deck (3/8″ x 6″ for 8′ 6″ wide trailer) Container Skid Plates Flush with Wood Deck (3/8″ x 10-1/2″ for 9′ wide trailer) Container Skid Plates Flush with Wood Deck (3/8″ x 14-3/4″ for 10′ wide trailer) |
| Deck Straps | Deck Straps Beside Outer Beam (1-1/4″ x 9″) Deck Straps Beside Inner Beam (1-1/4″ x 9″) |
| Landoll Traction Plate Over Wood 10′ Forward of Approach Plate | |
| Landoll Traction Plate on Approach (Bolt-on) | |
Deck – Additional
| Deck Type | 1-3/8″ Apitong Wood Decking (Standard) 1/8″ Steel Tread Plate Decking |
|---|---|
| Flag Holders | 2 Front Lower Deck and 2 Rear Lower Deck 2 Upper Deck, 2 Front Lower Deck, and 2 Rear Lower Deck |
| Flag and Oversized/Wide-Load Banner Kit (Includes 6 Flags and 2 Banners) | |
| Swing-Out Lights | Upper Deck Turn/Flashing Lights (NA w/Chain/Rub Rail) Lower Deck Turn/Flashing Lights Upper Deck Marker Lights, Amber Front, Red Rear (NA w/Chain/Rub Rail) Lower Deck Marker Lights, Amber Front, Red Rear Magnetic LED Amber Warning Lights (360°, battery powered) |
Tires & Rims
| 17.5 Machined Aluminum Wheel (Priced per tire) | |
|---|---|
| 17.5 Polished Aluminum Wheel (Priced per tire) | |
| 17.5 Machined Aluminum Wheel (Priced per tire) | |
| 17.5 Polished Aluminum Wheel (Priced per tire) | |
| Tires | 235/75R 17.5 Double Coin (Standard) 235/75R 17.5 Continental 245/70R 17.5 Michelin 255/70R 22.5 Double Coin 255/70R 22.5 Continental 255/70R 22.5 Michelin |
| Wheels – 17.5 Tires | 5 Steel Hub Wheel (8 Bolt) (Standard) 5 Machined Aluminum Wheel (8 Bolt) (Price for 3 axles outside only) 5 Polished Aluminum Wheel (8 Bolt) (Price for 3 axles outside only) |
| Wheels – 22.5 Tires | 5 Steel Hub Wheel (10 Bolt) (Standard) 5 Machined Aluminum Wheel (10 Bolt) (Price for 3 axles outside only) 5 Polished Aluminum Wheel (10 Bolt) (Price for 3 axles outside only) |
| Spare 235/75R 17.5 Double Coin Tires | 1 or 2 |
| Spare 235/75R 17.5 Continental Tires | 1 or 2 |
| Spare 245/70R 17.5 Michelin Tires | 1 or 2 |
| Spare 255/70R 22.5 Double Coin Tires | 1 or 2 |
| Spare 255/70R 22.5 Continental Tires | 1 or 2 |
| Spare 255/70R 22.5 Michelin Tires | 1 or 2 |
| Spare Wheel Type | 17.5 Steel Hub Wheel (8 bolt) (Standard) 17.5 Machined Aluminum Wheel (8 bolt) (1 or 2) 17.5 Polished Aluminum Wheel (8 bolt) (1 or 2) 22.5 Steel Hub Wheel (10 bolt) (Standard) 22.5 Machined Aluminum Wheel (10 bolt) (1 or 2) 22.5 Polished Aluminum Wheel (10 bolt) (1 or 2) |
| Tire Air System | Crossfire Air Equalizers |
| PSI Tire Inflation System | |
| Hubometer | |
| Dust Shields (for 22.5 Tires only) | |
Specifications
| Model | Capacity* | Base Weight | Length | Deck | Axles | Tires & Ply Rating |
|---|---|---|---|---|---|---|
| 455B-48 | 55 Ton | 21,980 lbs. (+/- 3%) | 47′-10″ | 102″ | 3 | (12) 235/75R 17.5 LRJ Double Coin |
| 455B-50 | 55 Ton | 23,010 lbs. (+/- 3%) | 49′-10″ | 102″ | 3 | (12) 235/75R 17.5 LRJ Double Coin |
| 455B-50CA | 55 Ton | 22,945 lbs. (+/- 3%) | 49′-10″ | 102″ | 3 | (12) 235/75R 17.5 LRJ Double Coin |
| 455B-53 | 55 Ton | 24,485 lbs. (+/- 3%) | 52′-10″ | 102″ | 3 | (12) 235/75R 17.5 LRJ Double Coin |
| 455B-57 | 55 Ton | Consult Factory | Consult Factory | 102″ | 3 | (12) 235/75R 17.5 LRJ Double Coin |
* Capacity ratings are frame capacities only. Actual load capacities may be restricted by factors such as gross axle weight ratings (GAWR) or state and federal regulations.
Specifications subject to change without notice.
Disclaimer: Landoll has a corporate policy of continuous product improvement and development, therefore, specifications are subject to change without any advance notice. Landoll is not responsible for differences between the specifications or illustrations contained on literature, data sheets, website and actual equipment.
