Rugged & Reliable
The 345F is a tandem-axle, pintle-hook, traveling-axle, four-beam trailer for hauling and ground loading pavers, graders, loaders, and other related equipment.
25-Ton Capacity
The 345F is designed to be pulled by a tandem-axle dump truck or other heavy-duty truck with pintle hookup. The GVWR of the trailer is 63,500 lbs. distributed and 40,000 lbs. concentrated within 10 feet at highway speeds.
Popular with the Department of Transportation
The 345F is commonly used by state DOT departments and other municipalities. It’s flat approach and deck allow the operator to easily and safely load track and crawler equipment without the aid of ramps or beavertail.
Features
Frame & General
| Capacity* | 25 Ton (50,000 lbs.) |
|---|---|
| Deck Rating | 40,000 lbs in 10′ |
| Estimated Base Weight | 13,500 lbs +/- 3% |
| Main Frame | Fabricated 80,000 PSI Yield Perimeter Beams – Fabricated Inner Beams 80,000 PSI Web and Top Flange, 100,000 PSI Bottom Flange |
| Crossmembers | 3″ and 4″ Jr. I-Beams Alternating on 8″ Centers |
| Hitch | 4′ Pintle Hook 15,000 lb. Vertical Load Eye with Adjustment of 23″-32″ from Ground Level |
| Deck Width | 102″ |
| Loaded Deck Height | 38″ |
| Loaded Ground Clearance | 20″ |
| Decking | 1-3/8″ Apitong Hardwood |
| Load Angle | 9° |
| Tool Box | Curb and Street Side Mounted with Lockable Door (14″H x 24″W x 24″D) |
| Tie Downs | Double Key Hole Chain Slots and Stake Pockets on 24″ Centers |
| Accessories | Approach Plate with (6) Key Hole Tie Downs |
| Parking Stands | Pin Drop |
* Capacity ratings are frame capacities only. Actual load capacities may be restricted by factors such as gross axle weight ratings (GAWR) or state and federal regulations.
Suspension & Undercarriage
| Suspension | Neway Air Ride RLU228, 22,500 lbs. Capacity |
|---|---|
| Undercarriage | (1) 4″ x 126″ |
| Grease | Centralized Grease System |
| Axles | (2) 25,000 lbs. Axles, Dual Tires, Oil Bath Bearings, Automatic Slack Adjusters |
| Axles Prepped for Air Inflation | |
| Brakes | 12.25 x 7.5 Full Air / Spring Brakes ABS, 4S2M |
| Tires | 235/75R 17.5 LRJ Double Coin Radial Tires |
| Rims | 17.5 x 6.75 Tubeless |
| Wheels | Steel Hub Pilot |
| Oil Seal Hubs | Internal Mated Assembly |
Hydraulics
| Hydraulic Hook Up | Quick Couplers 2,500 PSI – 20 GPM at Controls, 50 GPM Max |
|---|---|
| Tilt Cylinders | (2) 4″ Bore |
| Hydraulic Winch | No Winch Standard |
| Hydraulic Valve Body | Rexroth |
Electrical
| Air / Electrical | 7-Way Receptacle |
|---|---|
| Lights | Grote Clear Lens LED with Chrome Bezel (10-year warranty) |
| Wiring Harness | Grote “Xtreme” Wiring Harness (7-year warranty) |
Finish & Color
| Finish | Steel Grit Shot Blast to Bright Metal, Zinc Rich Primer |
|---|---|
| Powder Coat Color | White, Black, Yellow, Blue, Red, Green, Metallic Gray, Sapphire Blue |
| Decals | Hi-Visibility Reflective Package |
Options
Hitch
| 5′ Hitch for Tractor with 1′ Bed Overhang | |
|---|---|
| 7′ Hitch for Tractor with 3′ Bed Overhang | |
| Tilting Safety Latch Mounted on Hitch |
Winch & Accessories
| 12,000 lbs. Braden Winch | Front Mount |
|---|---|
| 20,000 lbs. Braden Winch | Front Mount |
| Cable Roller Guide (4-way Rollers) for Braden Winch 12K, 20K | |
| Winch Guard for Braden/Warn Winch | |
| Wireless Remote Control | Six Function |
| Dual Hydraulic Controls | Street and curb side (Not available with Engine Package) |
Tie Downs
| Recessed Mounted D-Rings (Each) (Not totally recessed with additional crossmembers) | |
|---|---|
| Flush Mounted D-Rings (Each) | |
| D-Ring Bolt-On at Winch (Only one location available) | |
| Single Slot Ratchet Winch for 4″ Nylon Strap (Weld-on – less strap; opposite side tie down required) |
Deck & Accessories
| 1/8″ Steel Tread Plate in lieu of Wood Standard | |
|---|---|
| 24″ Aluminum Pull-Out Extensions (Capacity not to exceed 50% of trailer capacity, Pull-Outs begin 63″ from front of trailer) |
Suspension & Undercarriage
| Spring Suspension Hutch 9,700 in lieu of Standard Air Ride | |
|---|---|
| Dock Level Hydraulic 62,000 lbs. 1 Pair | |
| Galvanized Bumper in lieu of Standard Painted Bumper |
Hydraulic Power Source
| Wet Kit for Tractor (Includes 30 Gallon Steel Tank) | Shipped loose with trailer or factory installed |
|---|---|
| Hydraulic Quick Couplers 1 Male / 1 Female (Matches trailer) (P/N 105902) | |
| Polished Aluminum Hydraulic Tank, (19″W x 24D”) (Side mount) in lieu of Standard | |
| 25 HP Kohler EFI Engine Package | No Curb Side Tool Box |
Tire & Rims
| Spare Double Coin Tire and Hub Pilot Type Rim (235/75R 17.5) | |
|---|---|
| Hubometer | |
| Pressure Guard Tire Inflation N/A |
Paint & Special
| Hot Dip Galvanizing (Trailer frame is totally submerged) | Adds minimum of 3 weeks to delivery |
|---|---|
| Paint Over Galvanizing | Sides only with Standard Colors only |
| Paint Over Galvanizing | Top surface only with Standard Colors only |
| Special Paint | Contact factory |
Specifications
| Model | Capacity* | Base Weight | Length | Deck | Axles | Tires & Ply Ratings |
|---|---|---|---|---|---|---|
| 345-35 | 25 Ton | 13,260 lbs. (+/- 3%) | 35′ | 102″ | 2 | (8) 235/75R 17.5 LRJ Double Coin |
| 345-36 | 25 Ton | Consult Factory | 36′ | 102″ | 2 | (8) 235/75R 17.5 LRJ Double Coin |
| 345-38 | 25 Ton | Consult Factory | 38′ | 102″ | 2 | (8) 235/75R 17.5 LRJ Double Coin |
* Capacity ratings are frame capacities only. Actual load capacities may be restricted by factors such as gross axle weight ratings (GAWR) or state and federal regulations.
Specifications subject to change without notice.
Disclaimer: Landoll has a corporate policy of continuous product improvement and development, therefore, specifications are subject to change without any advance notice. Landoll is not responsible for differences between the specifications or illustrations contained on literature, data sheets, website and actual equipment.
The information on any form of this website is intended only for the sole use of Landoll. We do not share or sell any of this information to third parties. This drawing and all information therein is property of Landoll and is confidential. It must not be made public or copied. This drawing is loaned subject to return upon demand and shall not be used directly or indirectly in anyway detrimental to our interest. Drawing illustrates standard equipment; optional equipment may change standard measurements.
