The 950E Traveling Tail is part of the 900 E Series.  The 950E is 50-Ton capacity and has three 25,000# axles. The 950E offers tail lengths of 12′ or 15′ tails and 45′, 48′ and 51′ overall lengths

VIEW LITERATURE
PRINT LITERATURE


Contact Trailer Sales

950E Traveling Tail

The 950E Traveling Tail is part of the 900 E Series. The 950E is a 50-Ton capacity and has three 25,000# axles. The 950E offers tail lengths of 12′ or 15′ tails and 45′, 48′ and 51′ overall lengths. The 950E offers the same rugged four beam construction and other outstanding features of the 900 E Series – standard powder coat paint, stable rigid dock arm, a tail-lifting capacity of 24,000 lbs. and a centralized grease system. Landoll is the only trailer manufacturer to offer powder coat paint on large trailer frames.

Why Own a 900 E Series

Quick, simple, safe operation and a longer wheelbase that increases payload. A 15′ tail reduces the load angle to a low 11°. Frames are steel shot blasted in preparation for the TGIC polyester powder coat paint finish standard on 900 Series trailer. The tail can raise and lift 24,000 lbs up to 57″ dock height. The 900 E Series is backed by a 5-year structural warranty.

Frame and Features

  • *Capacity: 50 Ton (100,000 lbs.)
  • Deck Rating: 70,000 lbs. in 10′
  • Estimated Base Weight: 19,890 lbs. (51′) +/-3%
  • Main Frame: Fabricated 100,000 PSI Yield 4-Beam Design
  • Crossmembers: 4″ Junior I-Beam and 3″ Junior I-Beam on 8″ Centers
  • Slope Drop: 90°
  • Parking Stands: Jost Two Speed Landing Gear
  • Pin Setting: 18″
  • Swing Clearance: 84″
  • Hitch: Fifth-Wheel Kingpin
  • Deck Width 102″
  • Loaded Deck Height: 38″
  • Loaded Ground Clearance: 20″
  • Decking: 1-3/8″ Apitong Hardwood (Lower Deck)
  • Tool Box: Twin Upper Deck Mounted Top-Opening with Non-Weight Bearing Lid Illuminated
  • Tie Downs: Double Key Hole Chain Slots / Square Stake Pockets on 16″ Centers / (6) Double Keyhole Chain Slots on Tail / (2) D-Rings Lower Deck at Slope
  • Tail Lifting Capacity: 24,000 lb.
  • Load Angle: 11° with 15′ Tail
  • Features: Automatic Slack Adjusters, Flat Approach Plate, Apitong Wood Covered Tail, Center Deck Keyholes on Tail, Bolt-On Traction Plate Over Approach Plate

Supspension and Undercarriage

  • Suspension: Neway Air Ride RLU228, 22,500 lb. Capacity with Manual Dump Valve
  • Undercarriage: Centralized Grease System
  • Axles: (3) 25,000 lb. Axles, Dual Tire, Oil Bath Bearings, Outboard Brake Drum, Automatic Slack Adjusters
  • Axles Prepped for Air Inflation
  • Brakes: 12.25×7.5 Full Air / Spring Brakes ABS 4S2M, Center Axle Indirect
  • Tires: 235/75R 17.5 LRJ Double Coin
  • Rims: 17.5×6.75 Tubeless
  • Wheels: Steel Hub Pilot
  • Oil Seal Hubs: Internal Mated Assembly

Hydraulics

  • Hydraulic Hook Up: Quick Couplers / 2,500 PSI – 20 GPM at Controls, 50 GPM Max
  • Hydraulic Winch: Upper Deck Worm Gear 12,000 lb. with 85′ of 1/2″ Cable with Wear Plate
  • Hydraulic Valve Body:  Rexroth

Electrical

  • Air / Electrical: 7-Way Receptacle
  • Lights: Grote MicroNova LED Clear Lens-Enhanced Stop, Tail & Turn; Rear Amber Strobe-10 Year Warranty
  • Wiring Harness: Grote “Xtreme” Wiring Harness (7-Year Warranty)

Finish and Color

  • Finish: Steel Grit Shot Blast to Bright Metal
  • Color:  Zinc Rich Primer
  • Powder Coat Color: White/Black/Yellow/Blue/Red/Green/Metallic Gray/Sapphire Blue
  • Decals: Hi-Visibility Reflective Package

Bulkheads:

  • 16″ / 24″ 2 – Position Bulkhead / Front Extension (Solid) (1,500 lb. Capacity 3,000 lb. Distributed) Powder Coated Black
  • 48″ High Mesh 102″ Powder Coated Black
  • Steel Bulkhead Wings
  • Aluminum Bulkhead Wings
  • Bolt-On Binder Storage Rack for 48″ Bulkheads
  • LED Work Light – Dual (Mounted on Bulkhead)
  • Aluminum Light Bar, Bulkhead Mounted, Includes Dual LED Work Lights, Stop / Turn / Tail Lights, Aluminum Chain / Binder Rack
  • Spare Tire Carrier – 48″ Bulkhead, Front Mounted
  • Spare Tire Carrier – 48″ Bulkhead, Rear Mounted
  • Spare Tire Carrier – Front Pocket Mt
  • Dual LED Strobe Beacons

Parking Stands:

  • Pin Drop in Lieu of Standard

Slope Ramp:

  • 6′ x 102″ Upper Deck Ramp (Air Operated) (10,000 lb. Capacity) (11.5° Load Angle)

Tie Down Rings:

  • Flush Mounted D-Rings (Each)
  • D-Ring Bolt-On at Winch (Each) (Two Locations Available)
  • Recessed Mounted D-Rings (Each) (Not Totally Recessed with Additional Crossmembers)

Winch and Accessories:

  • 20,000 lb. Worm Gear Winch in Lieu of 12,000 lb. Standard Upper Deck
  • 20,000 lb. Warn Planetary Winch, 2 Speed, with Air Release / Spring Tension in Lieu of Standard
  • 30,000 lb. Warn Planetary Winch, 2 Speed, with Air Release / Spring Tension in Lieu of Standard
  • Delete Standard 12,000 lb. Winch
  • Guard, Winch 12 / 20K (Cannot be Used in Conjunction with Pivoting Cable Roller Guide)
  • Cable Roller Guide for Winch – 12,000 lb. or 20,000 Lb. Slope or Upper Deck
  • Pivoting Cable Roller Guide for Winch with Air Tension / Air Release – 20,000 lb. Upper Deck Mount Only
  • Wireless Remote Control – Six Function for Rexroth Valve

Deck and Accessories:

  • Toolboxes- Non-Load Bearing Top Opening Toolboxes (Standard)
  • Toolboxes- Load Bearing, Self-Supporting, Top Opening Toolboxes
  • Toolboxes- Side Opening Toolboxes
  • Traction Bars for Tail – Weld On 12′ Tail (1” Sq. 6” Spacing) (Recommended when loading Track Equipment)
  • Traction Bars for Tail – Weld On 14’ Tail (1” Sq. 6” Spacing) (Recommended when loading Track Equipment)
  • Traction Bars for Tail – Weld On 15′ Tail (1” Sq. 6” Spacing) (Recommended when loading Track Equipment)
  • Bolt-On Steel Landoll Traction Plate over 1” Wood on Tail
  • Keyhole Tie Downs for Center Main Deck (Level with wood)
  • Lower Deck Bolt-On Lockable Tool Box (Curb Side or Street Side) (42″W x 28″D x 9″H)
  • 1 Pull-Out Step (Drivers Side and / or Curb Side Available)

Suspension and Undercarriage:

  • Air-Weigh Digital Scale System Bluetooth LoadMaxx Plus / Quickload Plus
  • Galvanized Bumper in Lieu of Standard Painted Bumper

Hydraulic Power Source:

  • Wet Kit for Tractor (Includes 30 gallon Steel Tank)
    • Shipped Loose with Trailer or Factory Installed
  • Polished Aluminum Hydraulic Tank, (19″W x 24D”) (Side Mount) in Lieu of Standard
  • Hydraulic Engine Package – Upper Deck with Cover Kohler EFI 25 HP Gas
  • Hydraulic Quick Couplers 1 Male / 1 Female (Matches Trailer) (P/N 105902)

Tire and Rims:

  • 235/75R 17.5 Continental Tires in Lieu of Stdandard
  • 245/70R 17.5 Michelin (Multi T) LRH Tires in Lieu of Standard (235 Not Available)
  • 255/70R 22.5 Double Coin Tires in Lieu of Standard
  • 255/70R 22.5 Michelin Tires in Lieu of Standard
  • Spare Double Coin Tire and Hub Pilot Type Rim (235/75R 17.5)
  • Spare Continental Tire and Hub Pilot Type Rim (235/75R 17.5)
  • Spare Michelin Tire and Hub Pilot Type Rim (245/70R 17.5)
  • Spare Double Coin Tire and Hub Pilot Type Rim (255/70R 22.5)
  • Spare Michelin Tire and Hub Pilot Type Rim (255/70R 22.5)
  • 17.5 Aluminum Wheel (8-Bolt Polished) in Lieu of Standard (Each)
  • 17.5 Aluminum Wheel (8-Bolt Machined) in Lieu of Standard (Each)
  • 22.5 Aluminum Wheel (10-Bolt Polished) in Lieu of Standard (Each)
  • 22.5 Aluminum Wheel (10-Bolt Machined) in Lieu of Standard (Each)
  • Hubometer
  • Pressure Guard Tire Inflation  N/A
  • Crossfire Air Equalizers (Price per Axle)

Paint and Special Options:

  • Hot Dip Galvanizing (Trailer Frame is Totally Submerged) – Adds Minimum of 3 Weeks to Delivery
  • Paint Over Galvanizing – Sides Only with Standard Colors Only
  • Paint Over Galvanizing – Top Surface Only with Standard Colors Only
  • Special Paint: Contact Factory

Specifications Table

Model Capacity Base Weight Length Tail Length Deck Axles Tires and Ply Rating
Model Capacity Base Weight Length Tail Lenght Deck Axles Tires and Ply Rating
950E-45-12 50 Ton Consult Factory 45′ 12′ 102″x 35’3″ 3 (12) 235/75R 17.5 LRJ Double Coin
950E-48-12 50 Ton 20,695 lbs. (+/- 3%) 48′ 12′ 102″x 38’3″ 3 (12) 235/75R 17.5 LRJ Double Coin
950E-48-15 50 Ton Consult Factory 48′ 15′ 102″ x 38’3″ 3 (12) 235/75R 17.5 LRJ Double Coin
950E-50-12 50 Ton Consult Factory 50′ 12′ 102″x 40’3″ 3 (12) 235/75R 17.5 LRJ Double Coin
950E-52-14 50 Ton Consult Factory 52′ 14′ 102″ x 40’3″ 3 (12) 235/75R 17.5 LRJ Double Coin
950E-48-15 50 Ton Consult Factory 48′ 15′ 102″x 41’3″ 3 (12) 235/75R 17.5 LRJ Double Coin
950E-51-15 50 Ton 21,750 lbs. (+/- 3%) 51′ 15′ 102′ x 42’3″ 3 (12) 235/75R 17.5 LRJ Double Coin
950E-53-15 50 Ton Consult Factory 53′ 15′ 102″x 43’3″ 3 (12) 235/75R 17.5 LRJ Double Coin

Line Drawing

Printable Line Drawing

950E-TrailerLineDrawings-LD950E_196448-0321

*Capacity ratings are frame capacities only. Actual load capacities may be restricted by factors such as gross axle weight ratings (GAWR) or state and federal regulations.

Specifications subject to change without notice.
